ETQP5M470YFM
Free Sample
Availability
Deliverable in short time
More information about samples availability can be found here: Availability
Power Choke Coil ETQP5M470YFM
Product Code:
255770
Weight: 1.5 g
Manufacturer: PANASONIC
Weight: 1.5 g
Manufacturer: PANASONIC
Detailed information
Monolithic Structure
Soft Saturation Characteristics
Magnetic Shielded
AEC-Q200 certified
Soft Saturation Characteristics
Magnetic Shielded
AEC-Q200 certified
For general questions
Technical Product Information
| Tolerance | +/-20% |
|---|---|
| Inductance | 48μH |
| Saturation Current | 4,1(ΔL -30%) A |
| DC Resistance | 156mΩ: |
| Series | PCC-M0754M |
| Maximum Category Temperature | 150°C |
| Pin Type | SMD |
| Minimale Category Temperature | -40°C |
| Height | 5,4mm |
